今日技术交流:美国Strongwell 公司推出新型玻璃纤维电线杆
中国玻璃纤维复合材料信息网 (cnbxfc.net) 发布日期: 2018-07-07  阅读: 324  字体:  双击鼠标滚屏

  近日,美国Strongwell公司设计并制造了新型的玻璃纤维电线杆,以代替原有的木制、钢制或混凝土电线杆。该复合材料电线杆由拉挤构件构成的,提供低导电性和高强度,比木材轻约30%,比钢轻约60%。其内部以泡沫为芯材,外部是树脂与玻璃纤维织物复合而成,确保其抗冲击性、耐久性和轻质高强,保证运输和使用过程的安全性。

原文如下:

ndensed="roboto-condensed" pt="pt">Fiberglass power poles for safer infrastructures

Strongwell designed a fiberglass power pole to directly replac existing wood, steel, and concrete poles.

微信图片_20180707082739

Electrical utility materials are regularly fabricated using wood, steel, or concrete. This is due to their innate versatility, and the fact that they have been established as building materials for decades. The first power poles ever erected were fabricated from wood, benefiting from excellent strength-to-weight ratios and good levels of ductility to resist wind-related damage. Electrical grids and extensive transmission line systems are now commonplace worldwide, with combinations of wood, steel, and concrete power poles found within these infrastructural systems. Yet these established industry materials exhibit the same mechanical drawbacks today as they did when electrical transmission setups were first established.

Wood is hygroscopic in nature and prone to rotting, while steel products rapidly oxidize and corrode in atmospheric conditions. Pollutants and weathering can degrade the mechanical stability of wood, steel, and concrete power poles, resulting in premature component failure and significant safety risks.

Fiberglass power poles provide comprehensive solutions to the problems of conventional materials. This article will explore the properties of fiberglass power poles and how they can improve infrastructural safety: capacities of fiberglass power poles.

Strongwell has designed a proprietary fiberglass power pole to directly replac existing wood, steel, and concrete poles. This lightweight product is constructed from pultruded components, providing low-conductivity and an improved strength-to-weight ratio over both wood and steel. It is roughly 30% lighter than wood and as much as 60% lighter than steel. This combination of mechanical stability and lightness is provided by a matrix of high-performance constituents, from an interior, multi-directional fiberglass fabric to a high-strength resin saturation.

The immediate benefit of this construction methodology is the negation of decay or rust. This radically improves the durability of the transmission array and reduces the risk of accidents due to mechanical failure. Power poles benefit further from the material structure of fiberglass due to its outstanding impact resistance. It features an internal foam core designed for impact adsorption, to reduce the danger to drivers in accidental traffic collisions. In several incidents wher vehicles have collided with fiberglass power poles, the impact was largely absorbed by the material’s structure, thus avoiding serious injury.

Fiberglass also offers benefits for installation and maintenance safety due to its lightweight nature and low-conductivity. Fiberglass power poles can be erected with reduced risk of strain or injury for workers with few special considerations for using the material. As it is low-conductive, it can be grounded similarly to wood power poles, reducing risks relating to unfamiliarity with the material. It can also be drilled for easy installation of critical transmission conductors and transformers.
